Venting hobs Novy Easy Prestige 1866

Type number: 1866

Venting hobs Novy Easy Prestige 1866 Enlarge
1866
1866
1866
1866
1866
1866
1866
See other versions of this product

Novy Easy Prestige 90 cmBlack

  • Elegant black powder-coated aluminium control knobs
  • One reference for recirculation and duct-out
  • Extra large cooking surface
  • Optimised airflow due to elegant finish
  • 4 cooking zones and convenient features
  • Suitable for surface or flush mounting
  • Monoblock recirculation filter with a lifespan of up to 450 cooking hours
  • Easy to maintain

£ 4,799 including VAT

Show dealers

Specifications

Cooking zones

Number of cooking zones
4 zones
Cooking zone specifications
ZoneZone dimension (mm)Zone power (W)Location of heating element
1240x2102100/3000Front left
2240x2102100/3000Rear left
3240x2102100/3000Rear right
4240x2102100/3000Front right

Energy label

Energy Efficiency class (EEIhood)
A+++
Annual Energy Consumption (kWh/year) (AEChood)
17,9
Lighting Efficiency class (LEhood)
Not applicable
Fluid Dynamic Efficiency class (FDEhood)
A
Grease Filtering Efficiency class (GFEhood)
B

Functions and features

Motor
Integrated
Number of motors
1
Sound absorber
Integrated
Recirculation
Optional
InTouch function
Not applicable
Auto stop
Yes
Delayed switch off
Yes
Delayed switch off (minutes)
30
Tower height (cm)
0
Number of grease filters
1
Grease filter cleaning indication
Yes
Recirculation filter cleaning indication
Yes
Diameter duct (mm)
222x89

Functions and features hobs

Flexzone activation
Manual
Flexzone
2
Grill function
No
Chef function
No
Pot move function
No
Automatic pan recognition
Yes
Keep warm function (°C)
42°C
Residual heat indication
Yes
Childproof lock
Yes
Pause function
Yes
Safety time-switch-off
Yes
Timers
Minute minder / Timer per Zone / Automatic cooking

Lighting

Dimensions

Product dimensions (WxDxH) (mm)
900 x 520 x 215
Diameter outlet (mm)
222x89
Position exhaust
Left / Back

Airflow and noise level

Free airflow (m³/h)
750
Airflow duct out speed 1 (m³/h)
220
Airflow duct out max powerspeed (m³/h) (Qboost)
610
Max pressure duct out at minimum speed (Pa)
46
Sound power duct out speed 1 (dB(A))
47
Sound power duct out at max powerspeed (dB(A)) (LWAboost)
70
Sound power duct out at minimum speed (dB(A)) (LWAmin)
47

Technical specifications

Maximum power (W)
7568
Voltage appliance (V)
230
Frequency (Hz)
50
Length power supply cable (m)
1,5
Power consumption in off-mode (Po) (W)
0
Power consumption in stand-by-mode (Ps) (W)
0,00
Net weight (kg)
18,9
See all specifications

Manuals & downloads

Technical File Exploded View User Manual Installation Manual Safety Instructions
