Hob + Hood Novy Easy Pro recirculation 1861
Type number: 1861
/Cooker hoods/Worktop/1861-Novy-Easy-black-80cm-detailed-image4.png?rmode=crop&width=538&height=538&format=webp)
/Cooker hoods/Worktop/1861-Novy-Easy-black-80cm-detailed-image4.png?rmode=crop&width=538&height=538&format=webp&quality=70)
/Hobs/Hob and Hood/1851-1861-Novy-Easy-black-90cm-ambient_frontview_loop_v4.jpg?rmode=crop&width=538&height=538&format=webp&quality=70)
/Hobs/Hob and Hood/1861-Novy-Easy-black-90cm-ambient_detail_v1.jpg?rmode=crop&width=538&height=538&format=webp&quality=70)
/Hobs/Hob and Hood/1851-1861-Novy-Easy-black-90cm-ambient_detail_v2.jpg?rmode=crop&width=538&height=538&format=webp&quality=70)
/Cooker hoods/Worktop/1861-Novy-Easy-black-80cm-detailed-image3.png?rmode=crop&width=538&height=538&format=webp&quality=70)
/Cooker hoods/Worktop/1861-Novy-Easy-black-80cm-ambient-image3.jpg?rmode=crop&width=538&height=538&format=webp&quality=70)
/Cooker hoods/Worktop/1861-Novy-Easy-black-80cm-ambient-image2.jpg?rmode=crop&width=538&height=538&format=webp&quality=70)
/Cooker hoods/Worktop/1861-Novy-Easy-black-80cm-ambient-image1.jpg?rmode=crop&width=538&height=538&format=webp&quality=70)
Novy Easy recirculation 80 cmBlack
- Optimised airflow due to elegant finish
- Easy maintenance
- Extra large cooking surface
- 4 cooking zones and useful functions
- Surface-mounting and flush-mounting possible
- Monoblock filter with a life span of up to 450 cooking hours
Optional
Specifications
Cooking zones
Number of cooking zones
4 zones
Cooking zone specifications
| Zone | Zone dimension (mm) | Zone power (W) | Location of heating element |
|---|---|---|---|
| 1 | 240x210 | 2100/3000 | Front left |
| 2 | 240x210 | 2100/3000 | Rear left |
| 3 | 240x210 | 2100/3000 | Rear right |
| 4 | 240x210 | 2100/3000 | Front right |
Energy label
Lighting Efficiency class (LEhood)
-
Functions and features
Motor
Integrated
Number of motors
1
Sound absorber
Integrated
Recirculation
Standard, Monoblock
InTouch function
Not applicable
Auto stop
Yes
Delayed switch off
Yes
Delayed switch off (minutes)
30
Tower height (cm)
0
Number of grease filters
1
Grease filter cleaning indication
Yes
Recirculation filter cleaning indication
Yes
Diameter duct (mm)
222x89
Functions and features hobs
Flexzone activation
Automatic
Flexzone
2
Grill function
Yes
Chef function
Yes
Pot move function
No
Automatic pan recognition
Yes
Keep warm function (°C)
70°C
Residual heat indication
Yes
Childproof lock
Yes
Pause function
Yes
Safety time-switch-off
Yes
Keep warm function (°C)
70°C
Timers
Minute minder / Timer per Zone / Automatic cooking
Lighting
Dimensions
Product dimensions (WxDxH) (mm)
800 x 520 x 215
Diameter outlet (mm)
222x89
Position exhaust
Left
Airflow and noise level
Free airflow (m³/h)
750
Airflow duct out speed 1 (m³/h)
172
Airflow duct out speed 4 (m³/h)
537
Airflow duct out max powerspeed (m³/h) (Qboost)
537
Sound power duct out speed 1 (dB(A))
44
Sound power duct out speed 4 (dB(A))
67
Sound power duct out at max powerspeed (dB(A)) (LWAboost)
67
Sound power duct out at minimum speed (dB(A)) (LWAmin)
44
Technical specifications
Maximum power (W)
7568
Voltage appliance (V)
230/400
Frequency (Hz)
50
Length power supply cable (m)
1,5
Net weight (kg)
18,8
